The Linear Microphone for the Micromate monitoring unit, automates the monitoring of air overpressure and vibration monitoring in the same unit, making it a cost effective and flexible device for these applications.
The Linear Microphone is calibrated to the ISEE-2022 standard with a frequency measuring range from 2 to 250 Hertz and an amplitude range up to 500 Pascals (0.0725 psi, or 148 dB).
Range of Applications
- Construction
- Dynamic Compaction
- Tunnels and Subways
- Blasting
- Demolitions
- Quarries
Specifications:
|
Response Standard
|
ISEE - 2022 |
|
Frequency Weighting
|
Linear
|
|
Frequency Range
|
2 Hz - 250 Hz
|
|
Amplitude Range
|
Up to 500 Pa (0.0725 psi, or 148 dB)
|
|
Trigger Levels
|
2 to 500 Pa (0.00029 to 0.0725 psi, or 100 dB(L) to 148 dB(L))
|
|
Sample Rates
|
1,024 - 4,096 S/s
|
|
Resolution
|
0.0156 Pa (0.05 dB)
|
|
Cable Length
|
2 m (6.6 ft)
|
|
Maximum Cable Length
|
75 m (246.1 ft)
|
|
Temperature Range
|
-40° to 50°C (-40° to 122°F)
|
